Ceiling Speaker
100.031UK
RC5
A wide range speaker with a 13cm (5.25") polypropylene cone with foam rubber surround to minimise distortion. The housing is made from white ABS with a rigid steel grille also in white to mount dis...
- 130mm (5.25") polypropylene wide range speaker
- Fitted with “dog-ear” mounts for quick installation
- Fitted with attractive metal grille
| Description | |
|---|---|
|
100.031UK
Ceiling speaker round white, 35W max. |
Ceiling Speaker
A wide range speaker with a 13cm (5.25") polypropylene cone with foam rubber surround to minimise distortion. The housing is made from white ABS with a rigid steel grille also in white to mount discreetly into a ceiling.
- 130mm (5.25") polypropylene wide range speaker
- Fitted with “dog-ear” mounts for quick installation
- Fitted with attractive metal grille
- Spring terminal connections
Specification
- Woofer 130mm (5.25") PP cone
- Frequency response 100Hz - 12kHz
- Power max. 35W
- Power rms 20W
- Impedance 8 ohms
- Cutout 170mmØ
- Mounting depth 54mm
- SPL max. 88dB
- Dimensions 60 x 190mmØ
- Weight 1.25kg
Trade information
| 100.031UK | |
|---|---|
| Barcode / EAN | 5015972016077 |
| Package type | Gift Box |
| Package dimensions | 87 x 215 x 220mm |
| Package weight | 1.25kg |
| Package quantity | 1 unit |
| Carton dimensions | 465 x 485 x 485mm |
| Carton weight | 25.00kg |
| Carton quantity | 20 packages |
| Pack paper weight | 0.08kg |
| Pack plastic weight | 0.01kg |
