IP ratings
IP (or "Ingress Protection") ratings are used to define levels of sealing effectiveness of electrical enclosures against intrusion from foreign bodies (tools, dirt etc) and moisture.
Weatherproof Oval LED Bulkhead Lights
154.588UK
BH9F-CW
Durable LED bulkhead lights in an impact-resistant housing with a white diffused cover. Designed to be wall or ceiling mounted for indoor or outdoor environments, providing illumination for walkway...
- Energy efficient LED light source
- Weatherproof IP65 rated
- Impact resistant polycarbonate housing
Weatherproof Oval LED Bulkhead Lights
Durable LED bulkhead lights in an impact-resistant housing with a white diffused cover. Designed to be wall or ceiling mounted for indoor or outdoor environments, providing illumination for walkways, entrances and exits.
- Energy efficient LED light source
- Weatherproof IP65 rated
- Impact resistant polycarbonate housing
- Easy screw-mount installation
Specification : Common
- Power supply 180-265Vac, 50/60Hz
- Power consumption 9W
- Housing material Polycarbonate
- IP rating IP65
- Connection 2-core, 1m cable
- Total luminous flux 720lm
- Luminous efficacy 80lm/W
- LED type SMD2835
- LED quantity 44
- Colour rendering index (CRI, Ra) >80
- Average lifetime 40,000hrs
- Beam angle 180°
- Operating temperature -25 to +45°C
- Dimensions 212 x 118 x 67mm
- Weight 250g
Specification : Versions
| 154.587UK | 154.588UK | |
|---|---|---|
| Colour temperature | 4000K | 6000K |
Trade information
| 154.587UK | 154.588UK | |
|---|---|---|
| Barcode / EAN | 5015972132159 | 5015972180426 |
| Package type | Box Label BW | Box Label BW |
| Package dimensions | 120 x 217 x 72mm | 120 x 217 x 72mm |
| Package weight | 0.27kg | 0.27kg |
| Package quantity | 1 unit | 1 unit |
| Carton dimensions | 450 x 620 x 310mm | 450 x 620 x 310mm |
| Carton weight | 13.50kg | 13.50kg |
| Carton quantity | 40 packages | 40 packages |
In the box
The box for this item contains :
- 9W LED bulkhead light
