Passive Speaker Cabinets

178.585UK CS-1560
Be the first to review

These speaker cabinets provide excellent clarity and definition for both music and vocal applications. Suitable for install or mobile use.

  • These cabinets feature high SPL drivers and wide dispersion horns with matched crossovers and carefully tuned enclosures
  • Cabinet construction features recessed metal handles
  • Recessed speaker sockets
Full description Find retailer
Description Version Packed
178.582UK
CS1245 speaker cabinet 30cm (12") - 450W 		12" Box Plain
178.585UK
CS1560 speaker cabinet 38cm (15") - 600W 		15" Box Plain

Passive Speaker Cabinets

These speaker cabinets provide excellent clarity and definition for both music and vocal applications. Suitable for install or mobile use.

  • These cabinets feature high SPL drivers and wide dispersion horns with matched crossovers and carefully tuned enclosures
  • Cabinet construction features recessed metal handles
  • Recessed speaker sockets
  • 2-way crossover
  • Horn protected
  • Black spatter finish
  • Robust foam covered metal grille
  • 35mmØ top-hat fitted underneath

Specification : Common

  • Connectors Speakon + 6.3mm
  • Impedance 8 ohms

Specification : Versions

  178.582UK 178.585UK
Power rms 450W 600W
Configuration 30cm (12") & horn 38cm (15") & horn
Crossover 2.5kHz (12dB) 2.5kHz (12dB)
Model CS1245 CS1560
Frequency response 48Hz-20kHz 45Hz-20kHz
SPL @ 1W/1m 98dB 100dB
Dimensions 610 x 410 x 375mm 715 x 485 x 400mm
Weight 22.5kg 30kg

Trade information

  178.582UK 178.585UK
Barcode / EAN 5015972034422 5015972034439
Package type Box Plain Box Plain
Package dimensions 486 x 530 x 710mm 512 x 600 x 810mm
Package weight 22.50kg 26.00kg
Package quantity 1 unit 1 unit
Carton dimensions 486 x 530 x 710mm 512 x 600 x 810mm
Carton weight 22.50kg 26.00kg
Carton quantity 1 package 1 package
