High Power Woofers with Aramid Fibre Cone

902.423UK QXW6
Be the first to review

A range of high-powered woofers with reinforced aramid fibre cones. Incorporating rubber surrounds, vented magnets and heat resistant 4 layer voice coils, these speakers can easily handle power pea...

  • Aramid fibre cone
  • Rubber surround
  • Vented magnet
Full description Find retailer
Description Version Packed
902.420UK
5.25" Woofer with Aramid fibre cone 		5.25" Gift Box
902.423UK
6.5" Woofer with Aramid Fibre cone 		6.5" Gift Box
902.426UK
8" Woofer with Aramid Fibre cone 		8" Gift Box

High Power Woofers with Aramid Fibre Cone

A range of high-powered woofers with reinforced aramid fibre cones. Incorporating rubber surrounds, vented magnets and heat resistant 4 layer voice coils, these speakers can easily handle power peaks, yet produce a smooth sound that will please any Hi-Fi enthusiast.

  • Aramid fibre cone
  • Rubber surround
  • Vented magnet
  • 4 layer voice coil
  • Black metal chassis
  • Spade terminals

Specification : Common

  • Impedance 8 ohms
  • Voice coil 4 layer

Specification : Versions

  902.420UK 902.423UK 902.426UK
Power max. 200W 250W 500W
Power rms 100W 125W 250W
Overall depth 80mm 90mm 95mm
Magnet diameter 100mmØ 120mmØ 140mmØ
Mounting centres 122mmØ 157mmØ 194mmØ
Diameter 130mm (5.25") 165mm (6.5") 200mm (8")
Frequency response 40Hz - 10kHz 35Hz - 8kHz 27Hz - 6kHz
Magnet weight 600g (20oz) 900g (30oz) 1.1kg (40oz)
SPL @ 1W/1m 84.8dB 88dB 85.5dB
Weight 1.27kg 1.92kg 2.76kg

Trade information

  902.420UK 902.423UK 902.426UK
Barcode / EAN 5015972053317 5015972053324 5015972053331
Package type Gift Box Gift Box Gift Box
Package dimensions 141 x 152 x 100mm 174 x 185 x 112mm 213 x 224 x 120mm
Package weight 1.50kg 2.00kg 3.00kg
Package quantity 1 unit 1 unit 1 unit
Carton dimensions 340 x 500 x 300mm 370 x 385 x 260mm 230 x 470 x 280mm
Carton weight 27.07kg 16.00kg 12.00kg
Carton quantity 18 packages 8 packages 4 packages
Pack paper weight 0.10kg 0.12kg 0.20kg
Pack plastic weight 0.00kg 0.00kg 0.01kg

Support

Thiele small parameters
Complete list of the thiele small parameters for this range of chassis speakers in Adobe Acrobat (.pdf) format
